Usb Rs485 Driver Download
1 Download USB TO RS485 drive.EXE file for Windows 7 / 8 / 8.1 / 10 / Vista / XP, save and unpack it if needed. 2 Switch on your new ports hardware. 3 Right click on the My computer icon and push Properties tab then. Choose Hardware tab. Click on Device Manager button. Joined: 9/28/2005. Last visit: 9/16/2020. Rating: (234) Hello, Drivers for cables and adapters are installed together with programming software installation.
U-485: USB to RS485 Serial Port Converter
The new U-485 is a USB-to RS485 converter that converts the PC's USB port directly to a two-wire RS485 interface. The converter is powered directly by the USB port and hence minimal wiring is required to connect your PC to any devices that has two-wire RS485 interface (e.g. All TRiLOGI brand of PLCs have at least 1 built-in RS485 port and on Nano-10 that's its only serial port).
With U-485 you can use the i-TRiLOGI + TLServer software to program a network of M-series, F-series and/or Nano-10 PLCs from a single PC. U-485 is also a great tool for trouble-shooting RS485 communication issues between devices.
| Documentation: 1. U-485 Setup Guide 2. U-485 Driver (Windows XP & Vista) 3. U-485 Driver (Windows 7) |
Notes:
1) For users whose PC already has a built-in RS232 port or USB-RS232 converter, another option is to use the Auto485 converter to convert the RS232 port into an RS485 port. However, since Auto485 is not port powered, it may be less convenient to use than the U-485 converter for programming purpose.
2) This converter is only used for converting a PC's USB port to RS485. It DOES NOT CONVERT a PLC's RS485 INTO a USB HOST port for connecting to say a mouse or a serial printer! USB to RS485 conversion is not a simple electrical interface changeover and therefore it is NOT possible for the PLC to interface to those standard USB peripherals such as a keyboard, a mouse or a USB Flash Drive.
| Quantity | Unit price |
|---|---|
| To1 | €39.00 * |
| 2 | €36.50 * |
| 5 | €35.00 * |
| 10 | €33.00 * |
| 25 | €31.00 * |
| 50 | €30.00 * |
| 100 | €29.00 * |
Prices plus VAT plus shipping costs
- Order number:95031010
The USB-Nano-485 changes signals between USB and RS-485. The device is specially designed for the two wire RS-485-bus. For this reason there are no confusing attachment and configuration settings.
The attachment is not complicated and debugging is simple in case of communication problems. The LEDs are shows: Power (yellow), Rx (green) and Tx (red).
Because of the extremely small dimensions the USB-Nano-485 is particularly usable for mobile use at notebooks. Stationary applications are however likewise possible.
For the RS-485 plug you can get a casing if needed to build your own connection cord.
Technical Data
Din regular free download mac. RS-485: 2-wire , up to 32 bus participants
data rate : up to 3 MBit/s
cable length : up to 2000m (at 128 kBit/s)
power consumption: 70mA (via USB port) no additional current supply necessarily
size: 12x20x74 (without plug)
- Converter
- Plugable terminal screw.
- USB cable 1,8m
USB extension cord 3m
